Tin-Can

Tin can is one of the safest materials , featuring complete tightness and non-transparency.It can safely and reliably protect the quality of the content , and can be easily classified after being used (separated with magnet ; other packing materials have no such characteristic).Its recycling can reach 80%. Tin-Can can be oxygenated , decomposed and returned to ferric oxide at the atmosphere , without causing environmental pollution.

Tin-Can can simultaneously meet the "low-polluting" , "recycling ",and "resource-saving" requirements.So it is believed that in the trend of seeking high living quality ,this Division will be able to maximize its potentiality with self-supply material and competitive edge of integrated production.


Download for Specifications

  • Ton Yi has lots of high technology and experience in manufacturing tin cans for foods and beverages, in coating and printing, and in producing tinplates tin mill black plates.






  • 1. TIN CAN (ROUND)

    CAN TYPE

    Specification
    (D × H)

    CAN HEIGHT
    (± 0.30mm)

    Volume of Content
    ( Full of water)
    (±2%:ml/.oz)

    NA1

    603×907

    239.2

    4300 ml(145.4)

    N1

    603×700

    177.6

    3120 ml(105.4)

    1#

    603×613

    173.0

    3055 ml(103.3)

    1B

    603×408

    114.6

    2000 ml(67.6)

    2#

    401×412

    121.0

    870 ml(29.4)

    2B

    401×400

    101.8

    740 ml(25.0)

    U2

    307×113

    46.0

    220 ml(7.4)

    U2

    307/305×113

    45.6

    220 ml(7.4)

    U2(2PCS)

    307×113

    45.5

    220 ml(7.4)

    U2(2PCS)

    307×111

    42.2

    200 ml(6.8)

    U2(2PCS)

    307×108

    38.4

    180 ml(6.1)

    U2(2PCS)

    307×105.5

    34.6

    160 ml(5.4)

    F2A

    307×202

    54.8

    260 ml(8.7)

    3#

    307×407

    113.0

    595ml(20.1)

    4#

    300×407

    113.0

    470 ml(15.9)

    4B

    300×400

    101.8

    410 ml(13.8)

    5#

    300×304

    83.0

    340 ml(11.5)

    6#

    300×205

    61.3

    246 ml(8.3)

    7#

    211×400

    101.0

    323 ml(10.9)

    320g(209D)

    209/211/209X408

    113.4

    348 ml(11.7)

    250g(209D)

    209/211/209X309

    91.4

    271 ml(9.1)

    350g(206D)

    206/211/209X413

    122.0

    371 ml(12.5)

    320g(206D)

    206/211/209X408

    113.5

    348 ml(11.7)

     280g(206D)

    206/211/209X401

    102.5

    320 ml(10.2)

     250g(206D)

    206/211/209X310

    91.6

    270 ml(9.1)

    250g
    (Stackable Multi-angular can) (Staclable Multi-angular)

    206/211/202X312

    94.7

    257 ml(8.6)

    240ml(200D)
    (Staclable Multi-angular)

    200/202/202X504

    133.0

    266 ml(8.9)

     H250g(200D)

    200/202/200X506

    136.8

    273 ml(9.2)

     H250g(200D)

    200/202/200X506

    136.8

    273 ml(9.2)

    190g(200D)

    200/202/200X402

    104.4

    203 ml(6.8)

    240g(curve can)

    113/206/202X406

    114.5

    259 ml(8.7)

    190g
    (Stackable Multi-angular can)

    113/206/202X310

    91.6

    208 ml(7.0)

    150g(113D)

    113/202/200X307

    87.8

    170 ml(5.7)


    2. TIN CAN (RECTANGULAR CAN)

    CAN  TYPE

    SpecificationDxH(mm)

    Caliber

    Volume
    (Liter)

    Application

    20L(High)

    238x380

    41D、56D
    68D、190D

    20

    for chemical & miscellaneous items.
    Outer lacquering:clear, white coating, golden.

    20L(Low)

    238x376

    28D、190D

    20

    for salad oil & miscellaneous items.
    Outer lacquering:clear, white coating.

    19L

    238x365

    56D、68D

    19

    for chemical items.
    Outer lacquering:clear

    18L

    238x350

    28D、38D
    41D、56D
    68D、100D
    150D、190D

    18

    for chemical & salad oil &
    miscellaneous items.
    Outer lacquering:clear, white
    coating, or golden.

    high-body cracker can

    238x367

    type of open top-end

    19

    for cracker & butter items.
    Outer lacquering:golden.

    low-body cracker can

    238x341

    type of open top-end

    17.5

    for cracker & butter items.
    Outer lacquering:clear, white coating, or golden.


    Remark:
    1.The information specified in the Remark column is based on the present production.
    2.The caliber and outer lacquering specified in the Remark column are done in accordance with the customer's requirement.
