Tin-Can
We are proud to be the only company in domestic that has acquired a Halal certificate for printing tin plates and metal cans.
Ton Yi has lots of high technology and experience in manufacturing tin cans for foods and beverages, in coating and printing, and in producing tinplates tin mill black plates.
-
Tin can is one of the safest materials , featuring complete tightness and non-transparency.It can safely and reliably protect the quality of the content , and can be easily classified after being used (separated with magnet ; other packing materials have no such characteristic).Its recycling can reach 80%. Tin-Can can be oxygenated , decomposed and returned to ferric oxide at the atmosphere , without causing environmental pollution.
Tin-Can can simultaneously meet the "low-polluting" , "recycling ",and "resource-saving" requirements.So it is believed that in the trend of seeking high living quality ,this Division will be able to maximize its potentiality with self-supply material and competitive edge of integrated production.
-
1. TIN CAN (ROUND)
CAN TYPE
Specification
(D × H)CAN HEIGHT
(± 0.30mm)Volume of Content
( Full of water)
(±2%:ml/.oz)NA1
603×907
239.2
4300 ml(145.4)
N1
603×700
177.6
3120 ml(105.4)
1#
603×613
173.0
3055 ml(103.3)
1B
603×408
114.6
2000 ml(67.6)
2#
401×412
121.0
870 ml(29.4)
2B
401×400
101.8
740 ml(25.0)
U2
307×113
46.0
220 ml(7.4)
U2
307/305×113
45.6
220 ml(7.4)
U2(2PCS)
307×113
45.5
220 ml(7.4)
U2(2PCS)
307×111
42.2
200 ml(6.8)
U2(2PCS)
307×108
38.4
180 ml(6.1)
U2(2PCS)
307×105.5
34.6
160 ml(5.4)
F2A
307×202
54.8
260 ml(8.7)
3#
307×407
113.0
595ml(20.1)
4#
300×407
113.0
470 ml(15.9)
4B
300×400
101.8
410 ml(13.8)
5#
300×304
83.0
340 ml(11.5)
6#
300×205
61.3
246 ml(8.3)
7#
211×400
101.0
323 ml(10.9)
320g(209D)
209/211/209X408
113.4
348 ml(11.7)
250g(209D)
209/211/209X309
91.4
271 ml(9.1)
350g(206D)
206/211/209X413
122.0
371 ml(12.5)
320g(206D)
206/211/209X408
113.5
348 ml(11.7)
250g(206D)
206/211/209X310
91.6
270 ml(9.1)
250g
(Stackable Multi-angular can) (Staclable Multi-angular)206/211/202X312
94.7
257 ml(8.6)
240ml(200D)
(Staclable Multi-angular)200/202/202X504
132.8
267 ml(8.9)
H250g(200D)
200/202/200X506
136.8
273 ml(9.2)
H250g(200D)
200/202/200X506
136.8
273 ml(9.2)
190g(200D)
200/202/200X402
104.4
203 ml(6.8)
240g(curve can)
113/206/202X406
114.5
259 ml(8.7)
190g
(Stackable Multi-angular can)113/206/202X310
91.6
208 ml(7.0)
150g(113D)
113/202/200X307
87.8
170 ml(5.7)
2. TIN CAN (RECTANGULAR CAN)
CAN TYPE
SpecificationDxH(mm)
Caliber
Volume
(Liter)Application
20L(High)
238x380
56D、68D、190D
20 for chemical & miscellaneous items.
Outer lacquering：clear, white coating, golden.20L(Low)
238x376
28D、190D
20 for salad oil & miscellaneous items.
Outer lacquering：clear, white coating.19L
238x365
41D、56D、68D
19 for chemical & salad items.
Outer lacquering：clear , printing18L
238x350
28D、38D
41D、56D
68D、100D
150D、190D18 for chemical & salad oil & miscellaneous items.
Outer lacquering：clear, white
coating, or golden.high-body cracker can
238x368
type of open top-end
19 for cracker & butter items.
Outer lacquering：golden.low-body cracker can
238x343
type of open top-end
17.5 for cracker & butter items.
Outer lacquering：clear, white coating, or golden.
Remark:
1.The information specified in the Remark column is based on the present production.
2.The caliber and outer lacquering specified in the Remark column are done in accordance with the customer's requirement. -
For more information,please contact:
TIN CAN (Round,Rectangular Can)
Daniel Chen
Tel No：886-6-2531131 Ext:601
Fax No：886-6-2539361
E-mail：jenlin@tonyi.com.tw
